Magnetic Float Level Switch

Name: Magnetic Float Level Switch
Brand: WELK Level

Float-operated level switch for clean liquid high-low alarms, pump protection and simple tank control.

DutyPoint level

SignalReed switch / contact

MountingSide / top

MediaClean liquids

Request quote Attach files

Why choose· 01

Built for your duty.

Simple switching

A magnetic float actuates a reed switch at the set level point.

Low-cost alarm duty

Good for clean liquid tanks where continuous level is not needed.

Custom stem or cable

Mounting length, float material and switch logic can be configured by tank layout.

Engineer-checked selection

WELK checks medium, alarm height, mounting orientation, connection, output logic, power, contact rating and material requirement so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

Magnetic float switches are mechanical point-level devices for high alarm, low alarm, pump start/stop or dry-run protection.

They are best used with clean liquids where the float can move freely without heavy buildup, viscosity or solids.

Magnetic Float Level Switch is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Point level switch selection starts from medium behavior, alarm point, mounting direction, density or dielectric, buildup risk, process connection, power and contact logic.

Specifications· 03

Magnetic Float Level Switch specification range.

Parameter	Value
Measuring principle	Magnetic float actuated switch
Output	Reed switch contact, SPST/SPDT by model
Mounting	Top, side or cable float by tank
Materials	304, 316L, PP or PVDF by medium
Use limit	Avoid heavy buildup or sticky media unless designed for it
RFQ data	Mounting orientation, switch point, liquid density, material and contact rating
Material options	silicone rubber
Temperature rating	- 0 ° c-170 ° C
Selection checks	Point level switch selection starts from medium behavior, alarm point, mounting direction, density or dielectric, buildup risk, process connection, power and contact logic.
Common limitations	Sticky buildup, coating, turbulence, low density solids, non-conductive liquids or tank-wall material can make one switch principle unsuitable.

Applications· 04

Where this product works.

Pump protectionOverflow alarmLow-level alarmSmall tanksHigh level alarmLow level alarmOverflow preventionSilo demand level

Level switch Magnetic level

Materials & outputs· 05

Wetted materials & output options.

304316L PPPVDFProcess connectionMounting bracketWetted material

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common magnetic float level switch specs.

Measuring principle Output Mounting Materials Use limit RFQ data

FAQ· 06

Magnetic Float Level Switch questions.

How do I choose the switching point for Magnetic Float Level Switch?

Start from medium, alarm height, mounting orientation, connection, output logic, power, contact rating and material requirement. WELK then confirms the exact model, material and output before quotation.

What is the difference between Magnetic Float Level Switch and continuous transmitter?

Magnetic Float Level Switch is selected for its specific duty and limitations. WELK compares it with continuous transmitter, radar, ultrasonic when the process data suggests another technology may be safer.

Can Magnetic Float Level Switch be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of Magnetic Float Level Switch?

Sticky buildup, coating, turbulence, low density solids, non-conductive liquids or tank-wall material can make one switch principle unsuitable.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.
