Magnetostrictive Level Gauge for Storage Tanks

Name: Magnetostrictive Level Gauge for Storage Tanks
Brand: WELK Level

High-accuracy magnetostrictive level gauge for clean liquid storage tanks, fuel tanks and chemical tanks.

PrincipleMagnetostrictive

Output4-20 mA / digital

AccuracyHigh accuracy class

UseStorage tank gauging

Request quote Attach files

Why choose· 01

Built for your duty.

Tank gauging focus

This product targets buyers searching for magnetostrictive level gauges rather than bypass magnetic indicators.

High-resolution output

The float position is converted into a continuous signal for PLC, tank gauging or local display systems.

Float and probe engineered

Probe length, float size and material are selected from tank height, density, pressure and medium compatibility.

Engineer-checked selection

WELK checks range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

Magnetostrictive level gauges are used for high-resolution continuous liquid measurement in clean liquid tanks, fuel tanks, oil tanks and selected chemical tanks.

WELK confirms liquid density, tank height, insertion method, probe material, required accuracy class, output protocol and hazardous-area requirement.

Magnetostrictive Level Gauge for Storage Tanks is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Magnetic and local gauge selection depends on center-to-center distance, density, pressure, temperature, flange standard, chamber material, visibility requirement and whether switches or a transmitter are needed.

Specifications· 03

Magnetostrictive Level Gauge for Storage Tanks specification range.

Parameter	Value
Measuring principle	Magnetostrictive float position measurement
Installation	Top insertion or chamber-mounted by tank layout
Output	4-20 mA, HART, RS-485 or digital by transmitter
Probe length	Customized to measuring range and tank height
Float	Selected from liquid density and pressure
RFQ data	Tank height, density, pressure, temperature, connection, output and accuracy requirement
Range / measuring length	40mm~20000mm
Accuracy class	Analog: 0.3% RS485: 0.1%,0.15mm
Material options	304 stainless steel
Output signal	Analog: 4-20mA Digital: RS485

Applications· 04

Where this product works.

Fuel storage tanksHydraulic oil tanksChemical tanksDay tanksTank gauging systemsBoilersPressure vesselsChemical storage

Magnetic level 316L Explosion-proof

Materials & outputs· 05

Wetted materials & output options.

316L304PTFEStainless SteelCustom rangeProcess connectionWetted materialExplosion-proof optionLogo/Marking

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common magnetostrictive level gauge for storage tanks specs.

Measuring principle Installation Output Probe length Float RFQ data

FAQ· 06

Magnetostrictive Level Gauge for Storage Tanks questions.

What dimensions are needed for Magnetostrictive Level Gauge for Storage Tanks?

Start from range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need. WELK then confirms the exact model, material and output before quotation.

What is the difference between Magnetostrictive Level Gauge for Storage Tanks and radar?

Magnetostrictive Level Gauge for Storage Tanks is selected for its specific duty and limitations. WELK compares it with radar, differential pressure, magnetostrictive transmitter when the process data suggests another technology may be safer.

Can Magnetostrictive Level Gauge for Storage Tanks be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of Magnetostrictive Level Gauge for Storage Tanks?

Very low density, viscous or dirty media, crystallization and high pressure/temperature require float and chamber review.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.

Need magnetostrictive level gauge for storage tanks? Send the conditions.

Attach tank drawings, old instrument photos or datasheets if available.
