Magnetostrictive Level Gauge / Transmitter

Name: Magnetostrictive Level Gauge / Transmitter
Brand: WELK Level

High-resolution continuous liquid level transmitter for magnetic gauge chambers or direct float-probe installation.

PrincipleMagnetostrictive

Output4-20 mA

ResolutionMillimeter class

UseContinuous liquid level

Request quote Attach files

Why choose· 01

Built for your duty.

High resolution

Magnetostrictive technology is selected when a higher-resolution remote signal is needed from a float-based measurement.

MLG retrofit option

External transmitters can be clamped to compatible magnetic level gauge chambers.

Interface potential

Dual-float or interface designs can be reviewed when liquids and densities are suitable.

Engineer-checked selection

WELK checks range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

A magnetostrictive transmitter determines the position of a magnetic float and converts it into a continuous analog or digital signal.

It is often paired with a magnetic level gauge to provide both local visual indication and control-room transmission.

Magnetostrictive Level Gauge / Transmitter is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Magnetic and local gauge selection depends on center-to-center distance, density, pressure, temperature, flange standard, chamber material, visibility requirement and whether switches or a transmitter are needed.

Specifications· 03

Magnetostrictive Level Gauge / Transmitter specification range.

Parameter	Value
Measuring principle	Magnetostrictive float position sensing
Output	4-20 mA; digital options by selected transmitter
Installation	External on bypass chamber or direct insertion by design
Resolution	Millimeter-class by selected transmitter
Media	Clean or compatible liquids with suitable float movement
RFQ data	Measuring range, chamber OD, float type, temperature, pressure and output
Display / transmitter	7 inch real colorful touch screen
Communication	RS485
Power supply	DC12V, 50mA
Range / measuring length	600~4000mm

Applications· 04

Where this product works.

Tank gaugingChemical vesselsMagnetic gauge retrofitInterface monitoringBoilersPressure vesselsChemical storageOil tanks

Application

Boilers & Process Vessels

Pressure vessels and thermal systems

Wetted materials & output options.

316L304PTFECustom rangeProcess connectionWetted materialExplosion-proof option

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common magnetostrictive level gauge / transmitter specs.

Measuring principle Output Installation Resolution Media RFQ data

FAQ· 06

Magnetostrictive Level Gauge / Transmitter questions.

What dimensions are needed for Magnetostrictive Level Gauge / Transmitter?

Start from range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need. WELK then confirms the exact model, material and output before quotation.

What is the difference between Magnetostrictive Level Gauge / Transmitter and radar?

Magnetostrictive Level Gauge / Transmitter is selected for its specific duty and limitations. WELK compares it with radar, differential pressure, magnetostrictive transmitter when the process data suggests another technology may be safer.

Can Magnetostrictive Level Gauge / Transmitter be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of Magnetostrictive Level Gauge / Transmitter?

Very low density, viscous or dirty media, crystallization and high pressure/temperature require float and chamber review.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.

Need magnetostrictive level gauge / transmitter? Send the conditions.

Attach tank drawings, old instrument photos or datasheets if available.
