Steam Jacket Magnetic Level Gauge

Name: Steam Jacket Magnetic Level Gauge
Brand: WELK Level

Magnetic level gauge with steam jacket or heat tracing for viscous liquids and temperature-maintained tanks.

HeatingSteam jacket / tracing

UseViscous liquids

IndicationLocal magnetic

OptionsSwitch / transmitter

Request quote Attach files

Why choose· 01

Built for your duty.

Prevents viscosity problems

Steam jacket or heat tracing helps keep waxy, viscous or crystallizing liquids fluid inside the chamber.

Process-matched heating

Heating medium pressure, temperature and connection layout must be matched to plant utilities.

Maintains visual level

Operators still get a local flapper indication while the chamber is temperature-maintained.

Engineer-checked selection

WELK checks range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

Steam-jacket magnetic gauges are selected for liquids that can thicken, crystallize or freeze if the bypass chamber cools down.

WELK confirms heating medium, jacket connection, insulation, liquid viscosity, pour point and process temperature before quote.

Steam Jacket Magnetic Level Gauge is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Magnetic and local gauge selection depends on center-to-center distance, density, pressure, temperature, flange standard, chamber material, visibility requirement and whether switches or a transmitter are needed.

Specifications· 03

Steam Jacket Magnetic Level Gauge specification range.

Parameter	Value
Configuration	Magnetic gauge with jacket or heat-tracing pipe
Heating medium	Steam, hot oil or electric tracing by project
Chamber	Stainless or lined chamber by medium
Indication	External magnetic flapper or roller
Options	Insulation, switch and 4-20 mA transmitter
RFQ data	Medium, viscosity, pour point, heating medium, pressure, temperature and range
Material options	SS304, SS316, PTFE, PP, PVC, PVDF
Range / measuring length	6000 mm, greater lengths on request
Accuracy class	+/- 5 mm
Pressure rating	<10.0 Mpa for SS & 0.3 Mpa for PP, PVC & PVDF

Applications· 04

Where this product works.

Heavy oil tanksSulfur service reviewViscous chemicalsCrystallizing liquidsBoilersPressure vesselsChemical storageOil tanks

Application

Boilers & Process Vessels

Pressure vessels and thermal systems

Wetted materials & output options.

316L304PTFEStainless SteelCustom rangeProcess connectionWetted materialExplosion-proof option

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common steam jacket magnetic level gauge specs.

Configuration Heating medium Chamber Indication Options RFQ data

FAQ· 06

Steam Jacket Magnetic Level Gauge questions.

What dimensions are needed for Steam Jacket Magnetic Level Gauge?

Start from range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need. WELK then confirms the exact model, material and output before quotation.

What is the difference between Steam Jacket Magnetic Level Gauge and radar?

Steam Jacket Magnetic Level Gauge is selected for its specific duty and limitations. WELK compares it with radar, differential pressure, magnetostrictive transmitter when the process data suggests another technology may be safer.

Can Steam Jacket Magnetic Level Gauge be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of Steam Jacket Magnetic Level Gauge?

Very low density, viscous or dirty media, crystallization and high pressure/temperature require float and chamber review.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.
