High-Pressure Magnetic Level Gauge

Name: High-Pressure Magnetic Level Gauge
Brand: WELK Level

Engineered magnetic level gauge for pressure vessels, separators and demanding process conditions.

PressureProject-engineered

ChamberHeavy-wall bypass

FloatDensity matched

OptionsSwitch / transmitter

Request quote Attach files

Why choose· 01

Built for your duty.

Engineered chamber

Chamber wall thickness, flange rating and welding standard are selected from design pressure and code requirement.

Float matched to density

The magnetic float must be designed for density, pressure, temperature and corrosion resistance.

Local plus remote options

Switches and transmitters can be added without sacrificing local indication.

Engineer-checked selection

WELK checks range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

High-pressure magnetic gauges are not catalog-only products; they should be engineered from design pressure, temperature, medium and code requirements.

WELK requests vessel drawings, flange standard, design conditions, specific gravity and whether total or interface level is required.

High-Pressure Magnetic Level Gauge is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Magnetic and local gauge selection depends on center-to-center distance, density, pressure, temperature, flange standard, chamber material, visibility requirement and whether switches or a transmitter are needed.

Specifications· 03

High-Pressure Magnetic Level Gauge specification range.

Parameter	Value
Configuration	Bypass magnetic level gauge
Pressure	Engineered to design pressure and flange rating
Chamber	Heavy-wall stainless or alloy chamber by project
Float	Designed from specific gravity, pressure and temperature
Options	Switches, transmitter, insulation, vent and drain
RFQ data	Design pressure, temperature, medium, density, flange standard and range
Temperature rating	≤200℃
Accuracy class	±5mm,3mm
Material options	Plastic,ABS,PC,SS
Range / measuring length	255-3668 or customizable

Applications· 04

Where this product works.

Pressure vesselsSeparatorsChemical reactorsBoiler auxiliary vesselsBoilersChemical storageOil tanksLocal indication

Application

Boilers & Process Vessels

Pressure vessels and thermal systems

Wetted materials & output options.

316L304Stainless SteelPTFECustom rangeProcess connectionWetted materialExplosion-proof option

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common high-pressure magnetic level gauge specs.

Configuration Pressure Chamber Float Options RFQ data

FAQ· 06

High-Pressure Magnetic Level Gauge questions.

What dimensions are needed for High-Pressure Magnetic Level Gauge?

Start from range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need. WELK then confirms the exact model, material and output before quotation.

What is the difference between High-Pressure Magnetic Level Gauge and radar?

High-Pressure Magnetic Level Gauge is selected for its specific duty and limitations. WELK compares it with radar, differential pressure, magnetostrictive transmitter when the process data suggests another technology may be safer.

Can High-Pressure Magnetic Level Gauge be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of High-Pressure Magnetic Level Gauge?

Very low density, viscous or dirty media, crystallization and high pressure/temperature require float and chamber review.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.

Need high-pressure magnetic level gauge? Send the conditions.

Attach tank drawings, old instrument photos or datasheets if available.
