Compact Tuning Fork Level Switch

Name: Compact Tuning Fork Level Switch
Brand: WELK Level

Mini tuning fork level switch for small tanks, pipes and compact liquid detection points.

ForkMini / compact

MountingG1/2 / G3/4 class

OutputPNP / NPN / relay

UseSmall tanks and pipes

Request quote Attach files

Why choose· 01

Built for your duty.

Compact fork size

Mini tuning fork switches fit small tanks, pipe sections and OEM equipment with limited space.

No float travel needed

The vibrating fork detects liquid presence without requiring a large moving float.

Fast point detection

Useful for overflow alarm, dry-run protection and simple interlock points.

Engineer-checked selection

WELK checks medium, alarm height, mounting orientation, connection, output logic, power, contact rating and material requirement so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

Compact tuning fork switches are a separate supplier catalog buying category because thread size, fork length and small body dimensions matter to OEM buyers.

WELK confirms liquid density, viscosity, thread, output, power supply and whether the switch is used for high or low alarm.

Compact Tuning Fork Level Switch is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Point level switch selection starts from medium behavior, alarm point, mounting direction, density or dielectric, buildup risk, process connection, power and contact logic.

Specifications· 03

Compact Tuning Fork Level Switch specification range.

Parameter	Value
Measuring principle	Vibrating tuning fork
Fork size	Compact fork for small process connections
Process connection	G1/2, G3/4, NPT or sanitary option by model
Output	PNP, NPN, relay or two-wire by electronics
Media	Liquids; density and viscosity checked by model
RFQ data	Thread, liquid, density, viscosity, output, power and alarm logic
Ingress protection	IP67
Range / measuring length	≤1MPa
Accuracy class	±5mm,0.5%
Material options	stainless steel

Applications· 04

Where this product works.

Small tanksPipelinesDosing skidsCooling systemsOEM machinesHigh level alarmLow level alarmPump protection

Level switch 316L

Materials & outputs· 05

Wetted materials & output options.

316LStainless SteelPTFEProcess connectionWetted materialLogo/Marking

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common compact tuning fork level switch specs.

Measuring principle Fork size Process connection Output Media RFQ data

FAQ· 06

Compact Tuning Fork Level Switch questions.

How do I choose the switching point for Compact Tuning Fork Level Switch?

Start from medium, alarm height, mounting orientation, connection, output logic, power, contact rating and material requirement. WELK then confirms the exact model, material and output before quotation.

What is the difference between Compact Tuning Fork Level Switch and continuous transmitter?

Compact Tuning Fork Level Switch is selected for its specific duty and limitations. WELK compares it with continuous transmitter, radar, ultrasonic when the process data suggests another technology may be safer.

Can Compact Tuning Fork Level Switch be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of Compact Tuning Fork Level Switch?

Sticky buildup, coating, turbulence, low density solids, non-conductive liquids or tank-wall material can make one switch principle unsuitable.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.

Need compact tuning fork level switch? Send the conditions.

Attach tank drawings, old instrument photos or datasheets if available.
