Insulated / Frost-Proof Magnetic Level Gauge

Name: Insulated / Frost-Proof Magnetic Level Gauge
Brand: WELK Level

Magnetic level gauge with insulation or frost-proof extension for low-temperature and outdoor service.

ProtectionInsulation / frost-proof

UseCold or outdoor tanks

IndicationExtended display

OptionsSwitch / transmitter

Request quote Attach files

Why choose· 01

Built for your duty.

Cold-service visibility

An extended indicator or insulation arrangement helps maintain readable local indication in cold environments.

Condensation control

Outdoor and low-temperature service may need frost protection, drain planning and weatherproof scale assemblies.

Engineered by temperature

The insulation thickness and indicator offset depend on operating temperature and site climate.

Engineer-checked selection

WELK checks range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need so the quoted configuration matches the application.

Application-matched configuration

Selection notes focus on real tank conditions, measuring range, process connection, output signal and installation limits.

Product details· 02

How it is selected & specified.

Insulated or frost-proof magnetic level gauges are used where the chamber needs thermal insulation but the indicator must remain visible.

WELK confirms minimum ambient temperature, process temperature, insulation thickness, rain/snow exposure and drain/vent arrangement.

Insulated / Frost-Proof Magnetic Level Gauge is presented as a configurable WELK product family. Final model limits, wetted materials, process connection, certificate and output signal are confirmed from the selected datasheet before quotation.

Magnetic and local gauge selection depends on center-to-center distance, density, pressure, temperature, flange standard, chamber material, visibility requirement and whether switches or a transmitter are needed.

Specifications· 03

Insulated / Frost-Proof Magnetic Level Gauge specification range.

Parameter	Value
Configuration	Bypass magnetic gauge with insulation or frost-proof indicator offset
Temperature	Project-confirmed low-temperature or outdoor service
Indication	Extended external flapper/roller assembly
Accessories	Scale, drain, vent, switch and transmitter options
Material	304, 316L or compatible alloy by medium
RFQ data	Process temperature, ambient minimum, insulation thickness, range and connection
Material options	SS316,SS304,Ti,alley
Pressure rating	10MPa, 16MPa
Range / measuring length	20cm-15m
Display / transmitter	LCD + magnetic flapper

Applications· 04

Where this product works.

Outdoor tanksLow-temperature storageCold-region plantsInsulated process vesselsBoilersPressure vesselsChemical storageOil tanks

Application

Boilers & Process Vessels

Pressure vessels and thermal systems

Wetted materials & output options.

316L304Stainless SteelCustom rangeProcess connectionWetted materialMounting bracket

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor head, probe/antenna/chamber support where needed, model label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common insulated / frost-proof magnetic level gauge specs.

Configuration Temperature Indication Accessories Material RFQ data

FAQ· 06

Insulated / Frost-Proof Magnetic Level Gauge questions.

What dimensions are needed for Insulated / Frost-Proof Magnetic Level Gauge?

Start from range or center-to-center distance, medium, density, pressure, temperature, flange standard, switch points and transmitter need. WELK then confirms the exact model, material and output before quotation.

What is the difference between Insulated / Frost-Proof Magnetic Level Gauge and radar?

Insulated / Frost-Proof Magnetic Level Gauge is selected for its specific duty and limitations. WELK compares it with radar, differential pressure, magnetostrictive transmitter when the process data suggests another technology may be safer.

Can Insulated / Frost-Proof Magnetic Level Gauge be customized?

Yes. Range, process connection, wetted material, output signal, cable length, display, switch points, documents and OEM label can be reviewed by product family.

What are the common limits of Insulated / Frost-Proof Magnetic Level Gauge?

Very low density, viscous or dirty media, crystallization and high pressure/temperature require float and chamber review.

Are the listed specifications final for every project?

No. Published values are typical selection ranges. WELK confirms final limits, material, output, certificate and documents from the actual process data before quotation.

Need insulated / frost-proof magnetic level gauge? Send the conditions.

Attach tank drawings, old instrument photos or datasheets if available.
